BAFANG 36V 250W Products Details : Position: Mid Motor. Construction: Geared Motor Rated Voltage (DCV): 36v Loading of 0W (Rpm): 83/87rpm. Rated Power (W): 350W Loading of 250W (Rpm): 75/80rpm.(75/80rpm) Max Torque: 80 N.m. Efficiency (%): ≥ 80%. Pedal Sensor: Speed sensor. Shaft Standard: JIS Weight (kg): 3.8 kg Speed Detection Signal (Pulses/Cycle): N/A Reduction Ratio: 1:21.9 Magnet Poles (2P): 16 Noise Grade ( dB): < 55 dB Hall Sensor: optional Connector: Waterproof. IP: IP 65 Certifications: CE/EN 14764/ROHS BAFANG 36V 350W Products Details : Position: Mid Motor. Construction: Geared Motor. Rated Voltage (DCV): 36 Loading of 0W (Rpm): 83/87rpm. Rated Power (W): 350W Loading of 250W (Rpm): 75/80rpm. Max Torque: 80 N.m. Efficiency (%): ≥ 80%. Pedal Sensor: Speed sensor.( Shaft Standard: JIS Weight (kg): 3.8 kg Speed Detection Signal (Pulses/Cycle): N/A Reduction Ratio: 1:21.9 Magnet Poles (2P): 16 Noise Grade ( dB): < 55 dB Hall Sensor: optional Connector: Waterproof. IP: IP 65 Certifications: CE/EN 14764/ROHS BAFANG 48V 350W Products Details: Position: Mid Motor. Construction: Geared Motor. Rated Voltage (DCV): 48V. Loading of 0W (Rpm): 83/87rpm Rated Power (W): 350W Loading of 250W (Rpm): 75/80rpm.(75/80rpm) Max Torque: 80 N.m. Efficiency (%): ≥ 80%. Pedal Sensor: Speed sensor. Shaft Standard: JIS Weight (kg): 3.8 kg Speed Detection Signal (Pulses/Cycle): N/A Reduction Ratio: 1:21.9 Magnet Poles (2P): 16 Noise Grade ( dB): < 55 dB Hall Sensor: optional Connector: Waterproof. IP: IP 65 Certifications: CE/EN 14764/ROHS BAFANG 36V 500W Products Details : Position: Mid Motor. Construction: Geared Motor. Rated Voltage (DCV): 36 Loading of 0W (Rpm): 110/130rpm. Rated Power (W): 500-750W Max Torque: 100 N.m. Efficiency (%): ≥ 80%. Pedal Sensor: Speed sensor. Shaft Standard: JIS Weight (kg): 4.2 kg Speed Detection Signal (Pulses/Cycle): N/A Reduction Ratio: 1:21.9 Magnet Poles (2P): 16 Noise Grade ( dB): < 55 dB Hall Sensor: optional Connector: Waterproof. IP: IP 65 Certifications: CE/EN 14764/ROHS BAFANG 48V 500W Products Details : Position: Mid Motor. Construction: Geared Motor. Rated Voltage (DCV): 48V Loading of 0W (Rpm): 110/130rpm. Rated Power (W): 500-750W Max Torque: 100 N.m. Efficiency (%): ≥ 80%. Pedal Sensor: Speed sensor. Shaft Standard: JIS Weight (kg): 4.2 kg Speed Detection Signal (Pulses/Cycle): N/A Reduction Ratio: 1:21.9 Magnet Poles (2P): 16 Noise Grade ( dB): < 55 dB Hall Sensor: optional Connector: Waterproof. IP: IP 65 Certifications: CE/EN 14764/ROHS BAFANG 48V 750W 8Fun Products Details: Position: Mid Motor. Construction: Geared Motor Rated Voltage (DCV): 48V. Loading of 750W (Rpm): 110/130rpm. Rated Power (W): 500-750W Max Torque: 100 N.m.( Efficiency (%): ≥ 80%. Pedal Sensor: Speed sensor. Shaft Standard: JIS Weight (kg): 4.2 kg Speed Detection Signal (Pulses/Cycle): N/A Reduction Ratio: 1:21.9 Magnet Poles (2P): 16 Noise Grade ( dB): < 55 dB Hall Sensor: optional Connector: Waterproof. IP: IP 65 Certifications: CE/EN 14764/ROHS
